SFAI (Air Type)(Smart Fault Automatic Interrupter)

ORC unit of the new design, which solve the mobility caused by ageing, provides the reliable circuit interruption performance without external arc of flame and completely prevents the switch from the arc caused by switching the load currents 400/ 630A at rated voltage

General  Description

EMT’s Smart FAI with the perfect Arch extinction performance is the gang operated Fault Automatic Interrupter for 15kV through 35kV on the overhead distribution feeders.

The  SFAI  have been specially designed for these live-switching duties :

♦ Motorising Full Load Current Breaking, Closing  Capability , and Load Transfer Switching

♦ Transformer Magnetizing Current Switching

♦ Cable Charging  Current  Switching

♦ Automatic Sectionalising  Operation with CT Integration

♦ Retrofitable SCADA system for Existing Manual LBS

  [ Optional  Function ]

♦SCADA operation function with RTU Integrating as DNP3.0, IEC101, IEC104 protocol

♦ SMART GRID Operation function with CT, RTU

♦ Mobile Phone monitoring and operation function  with GSM modem

EMT’s  SFAI equipped  high performance arch extinguishing chamber, and  switching operation with Motorizing, and Retrofitable Mechanism and Controller for Existing Manual LBS.

Features

High Reliability

       High Performance Arch-Chamber with Reliable switching mechanism parts.

       High rust-proof performance

Flexible and Retroffitable  Existing Manaul LBS to SFAI

       Available operation with Smart Grid system

       Automatic Sectionaliser Function

       Automatic Reclosing Function for Earth fault

       SCADA  operation Function

       Mobile phone Operation Function in Option

ItemUnitTechnical   Data
Rated VoltagekV122535
Maximum Rated VoltagekV152740.5
FrequencyHz50/6050/6050/60
Continuous CurrentA400/630400/630400/630
Rated Breaking CurrentA400/630400/630400/630
Short-Time Withstand Current(1sec)kA (Peak)25/32.525/32.525/32.5
Flash Over Voltage(1min) Dry/WetkV50/4060/5080/70
Impulse Withstand Voltage(BIL)kV100/110125/150170/200
Support  InsulatorPolymer, or Porcelain
OperationManual ,or  Motorizing
Apply  StandardIEC 60265-1 / IEC60129 / ANSI 37.41
Current  MonitoringCT  x 3 ea  Equipped
Automatic  SectionaliserWith Sectionalsing Controller
Scada  OperationOptionDNP3.0, IEC101, or IEC104
Smart  FunctionOptionMobile Phone Operation and Monitoring
Smart  Grid  Operation ApplicableOptionRemotely  Monitoring and Control
RetroffitableManual LBS  >>  Smart  FAI
